FMX Series High Precision Gear Flow Divider Motor (Hydraulic Synchronous Shunt Motor, Gear Flow Splitter)
FMX series gear flow divider motor is multi-section forced synchronous hydraulic component. With rigid synchronous shaft to evenly distribute oil for multi-cylinder synchronous movement, it owns flow dividing and pressure boosting dual functions. Compact aluminum housing, high synchronization accuracy, high pressure & contamination resistance, widely used in construction machinery, sanitation vehicles and lifting platforms.
Model | single outlet Displacement (ml/r) | 750rpm Minimum inlet flow(I/min) | 1500rpm standard inlet flow(1/min) | 3000rpm Maximun inlet flow(I/min) | Miximur outlet (Mpa) |
FMX-2*0.5 | 0.5 | 0.75 | 1.5 | 3.0 | 25 |
FMX-2*0.75 | 0.75 | 1.12 | 2.25 | 4.5 | |
| FMX-2*1.0 | 1.0 | 1.5 | 3.0 | 6.0 | |
| FMX-2*1.5 | 1.5 | 2.25 | 4.5 | 9.0 | 20 |
Core Advantages
- Precision ground gear pairs maintain even flow distribution under fluctuating loads.
Lightweight compact body, small overall size for mini hydraulic equipment layout.
Internal self-lubricating structure with great dirt resistance, lowering maintenance frequency.
Balanced oil circuit for noise reduction, low vibration during long continuous operation.
Universal standard mounting dimensions, direct replacement for imported dividers with lower cost.
Applications
- Construction machinery, sanitation vehicles, agricultural machinery, lifting platforms and industrial hydraulic synchronous equipment
1.OEM/ODM capabilities
2.Competitive pricing & bulk discounts
3.Fast shipping & customs clearance support
4.Turnkey project solutions
Standard Warranty: 12 months
Extended Warranty: Optional coverage up to 24 months.
Global Support: 24/7 technical assistance and spare parts supply.
Training: On-site or remote operation/maintenance training.
A: Standard models ship in 7-15 days; customized units require 30-45 days.
A: Yes, we have partnered service centers in key regions.
A: Absolutely! We offer tailored attachments.
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).
A: Contact us via email/phone for a quote, then confirm with a PO.
